Prf0199291 Prf0199291 Boxin Advance Plus @ Bl Mat / A / 90 90 cm built-in hood - Black - WiFi - Width (cm) 90

Boxin Advance Plus

The perimeter suction system allows this hood to remain hidden without interfering with furniture. It turns on automatically when it detects smoke; It connects to the hob and the propeller app.

Features
Many advantages enclosed in a single appliance. Its hidden design, flush with kitchen furniture, hides a latest generation engine: silent, powerful and low energy consumption. Smart sensors monitor the air all day and activate the hood if they detect vapors, to protect the furniture together with the side panels and the glass front shield. The hood also connects via Bluetooth to the propeller induction hob, automatically adjusting its power based on the quantity and quality of the detected smoke. You can also use your smartphone or voice assistant as a remote control.

Conditioned air
Clean air, healthy air. Automatically.
A sensor checks the quality of the air at any time of the day. If it detects vapors, even pollutants (such as solvents or cigarette smoke), the hood turns on and automatically adjusts the suction power. And turns off when the air comes clean.

Connectivity
Wi-fi and app: remote controls.
Our hoods can be operated via voice assistant and smartphone: with the propeller app you can turn it on or off, adjust the power, as well as the shade and intensity of the lights. Through this app you can promptly contact propeller assistance, keep the status of your filters under control (thanks to periodic notifications) and know if they need cleaning or maintenance.

Long-lasting filter
Anti-odor filters, duration.
Our anti-odor filters that are easy to maintain, are now even more green: washable and regenerable, with a duration of up to 3 years (compared to -3/6 months of average filters on the market).

Comfort silence
The power is there, but it is silent.
Kitchens are increasingly designed as open spaces, so they merge into one with their stay. Having a hood is becoming a must, as it will guarantee a perfect aspiration of fumes and smells without generating annoying noise. The extremely low noise level of our hoods and our suction hobs, ensures maximum wellness, so you can cook and converse with ease while you are committed to preparing your recipe.

Dim light

Shutdown delay

Wardrobe protection

Total integration

Perimeter aspiration

Maintenance alarm

Technical specifications

General data
Weight (kg) 10.8
Black finish
Dimensions (cm) 90
Energy class a
Minimum distance from the induction hob / radiant wall-mounted 43cm
Minimum distance from the roofing gas hob 57 centimeters
150mm conduit transition
LED strip lighting 1x7 W - 3500 K - 421 lux
Absorption 177W

Suction
Airflow min-max 180m³ / h - 640m³ / h
Level of noise min-max 45dB (a) - 57db (a)
Electronic 3S + B Controls Controls

Accessories
CFC0140343 coal filter
CFC0162221 regenerable carbon filter
H18.5 + 18.5 fireplace kit - kit0141458
H12 fireplace kit - kit0091876
Air diffuser grid kit Ø150 mm - kit0162617

Functions
Low light maintenance alarm
Comforting silence
Connectivity
Perimeter aspiration
Multiple delay switch or connection
Long-lasting filter
Total integration
AirMatic wardrobe protection without brushes

Models
Boxin ADV Plus @ IX / A / 60 PRF0191539
Boxin ADV Plus @ IX / A / 75 PRF0195605
Boxin ADV Plus @ IX / A / 90 PRF0195520
Boxin ADV Plus @ IX / A / 120 PRF0195342
Boxin ADV Plus @ Blmat / A / 60 PRF0199290
Boxin ADV Plus @ Blmat / A / 90 PRF0199291
Boxin ADV Plus @ Blmat / A / 120 PRF0199292
